motor constant >.69 #F/sqrt Watt
force constant >.59 #F/Amp
velocity constant 2.7 V/M/s
coil resistance .74 Ohms typ.
coil inductance 200 uHy
coil mass 21 gms
stator mass 110 gms
travel ± 1.25 mm typ.
max dissipation 3 Watts
size 1.5" w x 1.1" h x 1.3 l
This is a standard motor, if it does not fulfill your needs
we can design a custom motor.
Email or call with your requirements.
